Single-head precision jetting
A high-precision jetting system that reliably reproduces fine structures and tiny details.
CYLANCO · PRECISION SERIES 2026New
Cylanco-Gen1
Single-head compact precision wax jetting system
Ships with a mobile dedicated base for a complete wax-pattern workstation.
Core numbers
Precision, every day.
- 15μmLayer thickness
- 235 × 138 × 110mmBuild volume
- ±0.04mm / 20mmDimensional accuracy
- 2900 × 2900 × 1700DPIResolution
Print speed
Single channel 5 mm/h · Dual channel 2.5 mm/h
Single channel 5 mm/h · Dual channel 2.5 mm/h Single channel 7.2 mm/h · Dual channel 3.6 mm/h Speed varies by model, material and processBuilt for wax
A machine that feels like part of the team.
Enclosed chamber with a wide view
An enclosed workspace keeps every run stable while you watch the build in real time.
Mobile dedicated base
Casters and leveling feet in one — easy to move, easy to lock in place.
Specifications
Technical specifications
| 01 | Printing technology | Multi-nozzle jetting (MJP) |
|---|---|---|
| 02 | Build volume | 235 × 138 × 110 mm |
| 03 | Resolution | 2900 × 2900 × 1700 DPI, 15 μm layers |
| 04 | Dimensional accuracy | ±0.04 mm / 20 mm |
| 05 | Material efficiency | ≥57% build wax utilization |
| 06 | Print speed | Standard: single channel 5 mm/h, dual channel 2.5 mm/h; High speed: single channel 7.2 mm/h, dual channel 3.6 mm/h |
| 07 | Slicing software | WaxJetPrint |
| 08 | Input formats | STL、SLC |
| 09 | Connectivity | 10/100/1000 Ethernet, USB (Wi-Fi optional) |
| 10 | Supported OS | Windows 10 / Windows 11（64bit） |
| 11 | Power | AC 100-250 V，50-60 Hz，2.2 kW |
| 12 | Operating environment | Temperature 18-26°C, humidity 30-70% |
| 13 | Machine dimensions | 1050 × 540 × 1430 mm |
| 14 | Machine weight | 120 kg |
| 15 | Package dimensions | 1400 × 700 × 1650 mm |
| 16 | Package weight | 145 kg |
Let the next piece begin in wax.
Book a sample run and see how Cylanco-Gen1 fits your production flow.
